| Details | |
|---|---|
| Product code | RB941-2nD-TC |
| CPU nominal frequency | 650 MHz |
| CPU core count | 1 |
| Size of RAM | 32 MB |
| 10/100 Ethernet ports | 4 |
| Wireless chip model | QCA9533 |
| Wireless standards | 802.11b/g/n |
| Supported input voltage | 5 V - 5 V |
| Operating System | RouterOS |
| License level | 4 |
| Antenna gain DBI | 1.5 |
| CPU | QCA9533 |
| Max Power consumption | 3W |
| Number of chains | 2 |
| Storage type | FLASH |
| Storage size | 16 MB |
| 2.4 GHz | |||
|---|---|---|---|
| Transmit power (dBm) | Receive Sensitivity | Transmit power (mW) | |
| 1MBit/s | 22 | -96 | 158 |
| 11MBit/s | 22 | -89 | 158 |
| 6MBit/s | 20 | -93 | 100 |
| 54MBit/s | 18 | -74 | 63 |
| MCS0 | 20 | -93 | 100 |
| MCS7 | 16 | -71 | 40 |
wireless parameters may be limited in software, depending on your local regulatory limitations
| RB941-2nD-TC | QCA9531 (650Mhz) 100M all port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 32.5 | 394.8 | 94.0 | 385.0 | 173.6 | 88.9 |
| Bridging | 25 bridge filter rules | 32.5 | 394.8 | 56.1 | 229.8 | 56.7 | 29.0 |
| Routing | none (fast path) | 32.5 | 394.8 | 94.0 | 385.0 | 160.8 | 82.3 |
| Routing | 25 simple queues | 32.5 | 394.8 | 63.7 | 260.9 | 72.6 | 37.2 |
| Routing | 25 ip filter rules | 32.5 | 394.8 | 33.8 | 138.4 | 34.6 | 17.7 |
