CUDY M1200 (1-Pack) - AC1200 Wi-Fi Mesh Solution

CUDY M1200 AC1200 Wi-Fi Mesh Solution
Overview: The CUDY M1200 is an AC1200 wireless mesh system delivering up to 1.2 Gbps Wi-Fi speed and 3,000 sq.ft coverage. Ideal for homes, SMBs, and small offices requiring seamless roaming and high-performance network expansion.
Description: The CUDY M1200 features 2×2 internal omni-directional antennas and 802.11ac technology, providing 867 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band. Cudy Whole Home Mesh technology enables multiple units to interconnect, creating a broad and seamless network. Optional Ethernet backhaul can be used for even faster and more stable connections.
The device comes with advanced software features: VPN server and client support (PPTP/L2TP/OpenVPN/WireGuard/IPSec/Zerotier), guest network, DDNS (compatible with 15+ providers), NAT (Port Forwarding, UPnP, DMZ), and IPv6 support. It also supports TR-069 protocol and GenieACS/OpenACS for centralized management.
Multiple working modes (Wi-Fi Router, Access Point, Wi-Fi Extender, WISP) offer flexible deployment options. The 10/100 Mbps WAN and LAN ports, 12V/1A power adapter, and low power consumption ensure energy efficiency. Its compact design and easy installation allow for quick network integration.
Key Highlights:
- Dual-band AC1200 Wi-Fi: 867 Mbps (5 GHz) + 300 Mbps (2.4 GHz)
- Cudy Whole Home Mesh with seamless roaming and 3,000 sq.ft coverage
- VPN server/client support: PPTP, L2TP, OpenVPN, WireGuard, IPSec, Zerotier
- 1 × 10/100Mbps WAN + 1 × 10/100Mbps LAN port
- Advanced software: guest network, DDNS, NAT, IPv6
Technical Specifications:
| Parameter | Value |
|---|---|
| Manufacturer | CUDY |
| Model | M1200 |
| Product Group | Indoor Access Point |
| Wireless Standards | IEEE 802.11ac/n/a 5 GHz, IEEE 802.11n/b/g 2.4 GHz |
| Frequency | 5 GHz, 2.4 GHz |
| Signal Rate | 867 Mbps (5 GHz), 300 Mbps (2.4 GHz) |
| Antenna | 2 × Internal Omni-Directional Antennas |
| Interface | 1 × 10/100Mbps WAN Port, 1 × 10/100Mbps LAN Port |
| Buttons | Pair Button, Reset Button |
| External Power Supply | 12 V / 1 A |
| Flash | 128 Mbit (16 MB) |
| DDR | 1 Gbit (128 MB) |
| VPN Support | PPTP/L2TP/OpenVPN/WireGuard/IPSec/Zerotier (Server & Client) |
| Working Modes | Wi-Fi Router, Wireless Access Point, Wi-Fi Extender, WISP |
| Guest Network | 2.4 GHz guest network × 1, 5 GHz guest network × 1 |
| Wireless Security | WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| NAT | Port Forwarding, Port Triggering, UPnP, DMZ |
| Management | Access Control, Local Management, Remote Management, Wake on LAN |
| DNS | Cloudflare/Google/NextDNS/Custom |
| IPv6 | Relay, Dynamic (SLAAC/DHCPv6), Static (Fixed IP), Passthrough, MAP-E (Dual-stack), DS-Lite (Dual-stack) |
| Coverage | 3,000 sq.ft |
| Transmit Power | CE: <20 dBm (2.4 GHz), <23 dBm (5.15-5.25 GHz); FCC: <30 dBm (2.4 GHz & 5.15-5.825 GHz) |
| DDNS | Compatible with 15+ providers |
| CWMP Protocol | TR069 / TR098 / TR111 / TR181 |
| ACS Compatibility | GenieACS, OpenACS |
