Ubiquiti UniFi Access Point U6 Enterprise In-Wall (U6-Enterprise-IW)

Ubiquiti U6-Enterprise-IW UniFi Access Point
Overview: The Ubiquiti U6-Enterprise-IW is a Wi-Fi 6E access point designed for high-density enterprise networks and WISP deployments. It delivers high-performance wireless connectivity with 6 GHz support, a 2.5GbE uplink, and PoE+ power.
Description: The U6-Enterprise-IW is a tri-band Wi-Fi 6E access point operating on 2.4 GHz, 5 GHz, and 6 GHz. It features 4x4 DL/UL MU-MIMO on both 5 GHz and 6 GHz radios, and 2x2 UL MU-MIMO on the 2.4 GHz radio. It achieves data rates up to 4.8 Gbps on 5 GHz and 6 GHz, and up to 573.5 Mbps on 2.4 GHz. The 2.5GbE RJ45 uplink port ensures high-capacity wired connectivity, and the device is powered via PoE+. It is managed centrally through UniFi Network, offering advanced QoS, guest traffic isolation, VLAN (802.1Q), and robust wireless security including WPA3.
With support for over 600 concurrent clients, the U6-Enterprise-IW maintains high performance in dense environments such as offices, schools, hotels, and WISP sites. Zero Wait DFS eliminates waiting times on DFS channels. Its industrial operating temperature range (-30°C to 60°C) and noncondensing humidity range of 5-95% ensure reliability in harsh field conditions. The access point supports wall or ceiling mounting and features a durable polycarbonate/aluminium enclosure with stainless steel mounting hardware.
Key Highlights:
- Wi-Fi 6E (802.11ax) support on 2.4, 5, and 6 GHz bands.
- 4x4 MU-MIMO on 5 GHz and 6 GHz, 2x2 MU-MIMO on 2.4 GHz.
- 2.5GbE RJ45 uplink port and PoE+ power.
- 600+ concurrent client support and Zero Wait DFS.
- Centralized management via UniFi Network with advanced QoS.
- Industrial temperature range: -30°C to 60°C.
Technical Specifications:
| Parameter | Value |
|---|---|
| Manufacturer | Ubiquiti |
| Model | U6-Enterprise-IW |
| Product Group | UniFi Access Point |
| Dimensions | Ø220 x 48 mm (Ø8.7 x 1.9") |
| Weight | 960 g (without mount), 1090 g (with mount) |
| Enclosure Materials | Top: polycarbonate, Bottom: aluminium |
| Mount Material | Stainless steel (SUS304) |
| Networking Interface | (1) 2.5GbE RJ45 port |
| Management Interface | Ethernet, Bluetooth |
| Power Method | PoE+ |
| Power Supply | UniFi PoE switch, 48V, 0.5A PoE adapter (optional) |
| Supported Voltage Range | 44—57V DC |
| Max. Power Consumption | 22W |
| Max. TX Power | 2.4 GHz: 22 dBm, 5-7 GHz: 26 dBm |
| MIMO | 2.4 GHz: 2x2 (UL MU-MIMO), 5 GHz: 4x4 (DL/UL MU-MIMO), 6 GHz: 4x4 (DL/UL MU-MIMO) |
| Throughput Rate | 2.4 GHz: 573.5 Mbps, 5 GHz: 4.8 Gbps, 6 GHz: 4.8 Gbps |
| Antenna Gain | 2.4 GHz: 3.2 dBi, 5 GHz: 5.3 dBi, 6 GHz: 6 dBi |
| LEDs | White/blue |
| Buttons | Reboot and factory reset |
| Mounting | Wall/ceiling (Included) |
| Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| WiFi Standards | 802.11a/b/g, WiFi 4/WiFi 5/WiFi 6/WiFi 6E |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
| BSSID | 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest Traffic Isolation | Supported |
| Concurrent Clients | 600+ |
| Zero Wait DFS | Yes |
